Ultra low temperature freezers with climate-neutral refrigerants

{:en}[vc_row][vc_column][vc_column_text]Your Location: Main page > Equipment > Freezer[/vc_column_text][/vc_column][/vc_row][vc_row full_height="yes" columns_placement="top"][vc_column width="1/4"][vc_images_carousel images="4012,4010,4009,4011" img_size="full" autoplay="yes" wrap="yes" title="UFV SERIES"][/vc_column][vc_column width="3/4"][vc_column_text] The BINDER ultra low temperature freezer ensures the safe storage of samples at -80 °C. It combines outstanding environmental friendliness with low energy consumption, convenient operation and an individual safety concept.

Important characteristics

Available Sizes

Model	Interior Volume [L]	Outer Dimensions WxHxD mm	Internal Dimensions WxHxD mm
UF V 500	477	826 x 1966 x 938	606 x 1300 x 605
UF V 700	700	1110 x 1966 x 938	890 x 1300 x 605

[/vc_column_text][vc_tta_tabs][vc_tta_section title="Technical Data - UFV 500" tab_id="UFV500"][vc_column_text]

Designation	UFV500-230V
Option model	Standard
Order number	9020-0347
Measures
Interior volume [L]	477
Net weight of the unit (empty) [kg]	247
permitted load [kg]	200
Permitted load of individual compartment [kg]	50
Doors
Unit doors	1
Internal Dimensions
Width [mm]	606
Height [mm]	1300
Depth [mm]	605
Outer dimensions
Width net [mm]	826
Height net [mm]	1966
Depth net [mm]	938
Wall clearance sidewise [mm]	250
Wall clearance back [mm]	100
Environment-specific data
Energy consumption at set-point -80 °C and ambient temperature = 21 °C [kWh/d]	7.9
Sound-pressure level [dB(A)]	47
Fixtures
Number of shelves (std./max.)	Mar-13
Load-variants
Freezer racks per compartment	4
Cryoboxes, 50 mm	352
Performance Data Temperature
Temperature range [°C]	-86…-40
Temperature variation at -80 °C [± K]	2.5
Cooling down time from 22 °C to -80 °C [min]	360
Warm-up time during power failure from -80 °C / -122 °F to -60 °C / -76 °F [min]	230
Electrical data
Rated Voltage [V]	230
Power frequency [Hz]	50
Nominal power [kW]	1.6
Unit fuse [A]	10
Phase (Nominal voltage)	1~

[/vc_column_text][/vc_tta_section][vc_tta_section title="Technical Data - UFV 700" tab_id="UFV700"][vc_column_text]

Designation	UFV700-230V¹
Option model	Standard
Order number	9020-0348
Measures
Interior volume [L]	700
Net weight of the unit (empty) [kg]	288
permitted load [kg]	200
Permitted load of individual compartment [kg]	50
Doors
Unit doors	1
Internal Dimensions
Width [mm]	890
Height [mm]	1300
Depth [mm]	605
Outer dimensions
Width net [mm]	1110
Height net [mm]	1966
Depth net [mm]	938
Wall clearance sidewise [mm]	250
Wall clearance back [mm]	100
Environment-specific data
Energy consumption at set-point -80 °C and ambient temperature = 21 °C [kWh/d]	8.1
Average heat dissipation at set-point -80 °C and ambient temperature = 21 °C [W]	340
Sound-pressure level [dB(A)]	47
Fixtures
Number of shelves (std./max.)	Mar-13
Load-variants
Freezer racks per compartment	6
Cryoboxes, 50 mm	528
Performance Data Temperature
Temperature range [°C]	-86…-40
Temperature variation at -80 °C [± K]	2.5
Temperature fluctuation at -80 °C [± K]	1.5
Cooling down time from 22 °C to -80 °C [min]	450
Warm-up time during power failure from -80 °C / -122 °F to -60 °C / -76 °F [min]	250
Electrical data
Rated Voltage [V]	230
Power frequency [Hz]	50
Nominal power [kW]	1.6
Unit fuse [A]	10
Phase (Nominal voltage)	1~

[/vc_column_text][/vc_tta_section][/vc_tta_tabs][/vc_column][/vc_row]{:}{:zh}

重要特性

可选容积

型号	内部容积 [L]	外壳尺寸 宽 x 高 x 深 (mm)	内部尺寸 宽 x 高 x 深 (mm)
UF V 500	483	830x1985x885	619x1300x600
UF V 700	711	1120x1985x885	911x1300x600

{:}

Series ED-S | Drying and heating chambers Solid.Line with natural convection

[vc_row][vc_column][vc_column_text] The new products in the Solid.Line impress with their tried-and-tested BINDER quality and reliability. They are suited to drying and heating. The attributes of the Solid.Line are geared towards the application in question and therefore used in research and quality assurance.[/vc_column_text][vc_row_inner][vc_column_inner width="1/3"][vc_column_text][/vc_column_text][/vc_column_inner][vc_column_inner width="2/3"][vc_column_text].

Important characteristics

[/vc_column_text][/vc_column_inner][/vc_row_inner][/vc_column][/vc_row][vc_row][vc_column][vc_column_text]

Model	Housing Dimensions (excluding fittings and connections) W x H x D (mm)	Internal Dimensions W x H x D (mm)	Net weight (kg)	Interior volume (L)
ED-S 56	590 x 580 x 515	400 x 440 x 350	41	62
ED-S 115	740 x 790 x 555	550 x 550 x 390	57	118

． [/vc_column_text][/vc_column][/vc_row]

Series FD-S | Drying and heating chambers Solid.Line with forced convection

[vc_row][vc_column][vc_column_text] The new products in the Solid.Line impress with their tried-and-tested BINDER quality and reliability. They are suited to drying and heating. The attributes of the Solid.Line are geared towards the application in question and therefore used in research and quality assurance.[/vc_column_text][vc_row_inner][vc_column_inner width="1/3"][vc_column_text][/vc_column_text][/vc_column_inner][vc_column_inner width="2/3"][vc_column_text].

Important characteristics

[/vc_column_text][/vc_column_inner][/vc_row_inner][/vc_column][/vc_row][vc_row][vc_column][vc_column_text]

Model	Housing Dimensions (excluding fittings and connections) W x H x D (mm)	Internal Dimensions W x H x D (mm)	Net weight (kg)	Interior volume (L)
FD-S 56	590 x 580 x 515	400 x 440 x 350	41	55
FD-S 115	740 x 790 x 555	550 x 550 x 390	57	106

[/vc_column_text][/vc_column][/vc_row]
